Product Features
- Fully sealed stainless steel structure: The sensor part adopts a fully sealed stainless steel construction with integrated design, ensuring high stability and reliability.
- Imported pressure-sensitive core: Equipped with an imported piezoresistive sensing element, featuring high precision (≤0.25%FS) and stable output signals.
- Integrated electronic circuit: The electronic circuit housing is made of cast stainless steel for easy installation.
- IP68 high protection rating: Capable of long-term operation in water, with excellent waterproof, anti-seepage, and corrosion-resistant properties.
- Suitable for gas and liquid pressure and level detection environments.
- Designed with intelligent power management and reverse polarity protection for safe and reliable use.
Technical Specifications
| Parameter | Unit | Value |
|---|---|---|
| Measuring Range | mH₂O | Customizable range from 1 to 500 mH₂O |
| Total Error | %FS | ≤ 0.25 |
| Wiring System | / | 2-wire system / 3-wire system |
| Output Signal | mA | (4~20)mA / (0~5)V / (1~5)V / (0~10)V |
| Supply Voltage | VDC | 8~30 VDC |
| Operating Temperature | ℃ | -40 ~ +85℃ |
| Storage Temperature | ℃ | -40 ~ +85℃ |
| Insulation Resistance | MΩ @ V | > 100 MΩ (at 50VDC) |
| Housing Material | / | Stainless Steel |
| Electrical Connection | / | Cable |
| Response Time | ms | 10 ms |
| Safe Overload | %FS | 150 |
| Protection Rating | / | IP68 |
