Product Features
- Adopts an imported chip with high precision and excellent stability.
- High-quality stainless steel housing with an elegant appearance and strong corrosion resistance.
- RS485 digital signal output, featuring strong anti-interference capability, long transmission distance, and support for multi-point data communication.
- Hirschmann connector for the electrical interface, enabling easy sensor connection.
- Suitable for industrial automation control, hydraulic/pneumatic systems, petrochemical, environmental monitoring, and more.
- Designed with ultra-strong anti-interference and reverse polarity protection.
Technical Specifications
| Parameter | Unit | Value |
|---|---|---|
| Measuring Range | MPa | Customizable range from 1 to 60 MPa |
| Total Error | %FS | ≤ 0.5 / ≤ 0.1 |
| Wiring System | / | 4-wire system |
| Output Signal | / | RS485 |
| Supply Voltage | VDC | 8~30 VDC |
| Operating Temperature | ℃ | -40 ~ +85℃ |
| Storage Temperature | ℃ | -40 ~ +85℃ |
| Insulation Resistance | MΩ @ V | > 100 MΩ (at 50VDC) |
| Housing Material | / | Stainless Steel |
| Electrical Connection | / | Cable |
| Response Time | ms | 10 ms |
| Safe Overload | %FS | 150 |
| Protection Rating | / | IP68 |
