Product Features
- High-precision pressure-sensitive core: Adopts a diffused silicon pressure chip, delivering high measurement accuracy and excellent long-term stability.
- High-quality elastic structure: Combines high-precision resistance strain gauges with an all-stainless steel elastic body and temperature compensation technology.
- Weather-resistant protective housing: All-stainless steel casing with superior anti-seepage, waterproof, and corrosion-resistant properties.
- Standard quick-install interface: Features an M20×1.5 threaded interface for easy installation and strong compatibility.
- Suitable for various working conditions including industrial automation, water treatment, petrochemical, HVAC systems, and more.
- Designed with intelligent power management and reverse polarity protection for safe and reliable use.
Technical Specifications
| Parameter | Unit | Value |
|---|---|---|
| Measuring Range | MPa | 30 / 60 / 90 MPa |
| Total Error | %FS | ≤ 0.5 |
| Wiring System | / | 2-wire system / 3-wire system |
| Output Signal | mA / V | (4~20)mA / (0.5~4.5)V / (0.1~2.1)V / (0.25~2.25)V |
| Supply Voltage | VDC | 8~30 / 8~30 / 3~5 / 3~5 VDC |
| Operating Temperature | ℃ | -40 ~ +85℃ |
| Storage Temperature | ℃ | -40 ~ +85℃ |
| Insulation Resistance | MΩ @ V | > 100 MΩ (at 50VDC) |
| Housing Material | / | Stainless Steel |
| Electrical Connection | / | Cable |
| Response Time | ms | 10 ms |
| Safe Overload | %FS | 150 |
| Protection Rating | / | IP66 |
